Panoramic Ecosy+ Panoramic Defra Approved 5kw Eco Design Ready - Woodburning Stove Ecosy+ Panoramic Defra Approved 5kw Eco Design Ready - Woodburning Stove https://www.stoveworlduk.co.uk/image/cache/catalog/stoves/contemporary-stoves/ecosy-panoramic-defra-approved-5kw-eco-design-ready-2022-woodburning-stove-5-year-guarantee-485x485.jpg

class="embed-responsive embed-responsive-16by9" style="text-align:center;margin-bottom:18px;">

class='row two-col-stove-description'>

class='col-xs-12 col-md-6'>

Eco Design Approved

The Defra Approved 5kw Ecosy+ Panoramic Slimline is one of the most up to date stoves on the market. It has been tested and approved to meet the new Eco Design requirements which was made mandatory for all stoves manufactured from 2022 onwards, making this stove for now and the future. These test results have been approved by the SIA and listed on their official website. Want to find out more? Follow the link attached. stoveindustryalliance.com.

Slimline

This stove answers a lot of customers' problems - they need a physically large wood only stove but can only install one with a 5kw output. This has been achieved with this model by clever design. The external body is very wide (560mm) but the depth of the stove is shallow (314mm). The Panoramic also has a twin layer construction - the inner layer has been tapered in at the sides making the fire box slightly smaller and therefore reducing the potential heat output. The firebox is still 400mm wide meaning large logs are not a problem.

This version is Defra-approved. Non-Defra-approved version also available.

About

This advanced wood burning stove has been designed by Ecosy+ of Hampshire and rigorously tested at KIWA Gastec in Cheltenham to CE and British standards along with the ERP testings for Eco Design ratings.

This stove proves there is no need to spend £1000+ to get an advanced, good quality stove. Some of the features on this stove include a huge, fully heat-resistant, ceramic glass-fronted door that gives an amazing view of the fire. Those of you who have had fires before will know this a big plus of owning a stove. The stove is a fully welded construction that includes a 5mm thick body and 10mm thick top. We are so confident of its quality that we offer a 5 year guarantee; something that is not offered on any other stove around this price bracket.

We have tried to give the Defra-approved Panoramic wood burning stove a very minimal aesthetic and have therefore tucked away the air controls under the bottom ash lip which allowed us to increase the glass size for a maximised view of the fire. The stove's air supply is solely drawn in from the rear and regulated by the sliding control on the front. This advanced design makes the stove adaptable for a "direct air feed" which is perfect for new homes. The dimensions of this outlet is 90mm internal diameter and 100mm external diameter. - Note - On a standard install you will not require a direct air feed kit or an air brick installed in the room for this stove. This will only apply for new builds.

We also have a stand/bench available for this stove. The stand is 275mm high and will provide log storage as well as increasing the stoves height.

Clean Burn System

The Ecosy+ has an advanced seconday/tertiary clean burn system. On more advanced units like this one, it is common to have the air fed in from the rear and split off to be fed under the fire, over the fire (Secondary burn) and over the glass to help keep it clean and clear (Airwash system). The secondary burn feature is a real advantage as this re-burns the initial gasses and smoke produced from the fire. This means you are getting every drop of heat from your fuel and in turn will save you filling the stove up as often, saving you money and time on fuel.

5 Year Guarantee

This covers the stove's body and not the internal perishable parts l 582 654.00 In Stock

Ecosy+ Panoramic Defra Approved 5kw Eco Design Ready - Woodburning Stove

  • Brand: Panoramic
  • Product Code: Panoramic 5
  • Availability: In Stock
5 Year Guarantee
clearSkies 4
  • Price: £654.00

  • Ex Tax: £545.00

Available Options


82 reviews



Eco Design ApprovedCheap Woodburning Stoves

The Defra Approved 5kw Ecosy+ Panoramic Slimline is one of the most up to date stoves on the market. It has been tested and approved to meet the new Eco Design requirements which was made mandatory for all stoves manufactured from 2022 onwards, making this stove for now and the future. These test results have been approved by the SIA and listed on their official website. Want to find out more? Follow the link attached. stoveindustryalliance.com.

SlimlineAbout this Woodburning Stove

This stove answers a lot of customers' problems - they need a physically large wood only stove but can only install one with a 5kw output. This has been achieved with this model by clever design. The external body is very wide (560mm) but the depth of the stove is shallow (314mm). The Panoramic also has a twin layer construction - the inner layer has been tapered in at the sides making the fire box slightly smaller and therefore reducing the potential heat output. The firebox is still 400mm wide meaning large logs are not a problem.

This version is Defra-approved. Non-Defra-approved version also available.

AboutAbout this Woodburning Stove

This advanced wood burning stove has been designed by Ecosy+ of Hampshire and rigorously tested at KIWA Gastec in Cheltenham to CE and British standards along with the ERP testings for Eco Design ratings.

This stove proves there is no need to spend £1000+ to get an advanced, good quality stove. Some of the features on this stove include a huge, fully heat-resistant, ceramic glass-fronted door that gives an amazing view of the fire. Those of you who have had fires before will know this a big plus of owning a stove. The stove is a fully welded construction that includes a 5mm thick body and 10mm thick top. We are so confident of its quality that we offer a 5 year guarantee; something that is not offered on any other stove around this price bracket.

We have tried to give the Defra-approved Panoramic wood burning stove a very minimal aesthetic and have therefore tucked away the air controls under the bottom ash lip which allowed us to increase the glass size for a maximised view of the fire. The stove's air supply is solely drawn in from the rear and regulated by the sliding control on the front. This advanced design makes the stove adaptable for a "direct air feed" which is perfect for new homes. The dimensions of this outlet is 90mm internal diameter and 100mm external diameter. - Note - On a standard install you will not require a direct air feed kit or an air brick installed in the room for this stove. This will only apply for new builds.

We also have a stand/bench available for this stove. The stand is 275mm high and will provide log storage as well as increasing the stoves height.

Clean Burn SystemClean Burn

The Ecosy+ has an advanced seconday/tertiary clean burn system. On more advanced units like this one, it is common to have the air fed in from the rear and split off to be fed under the fire, over the fire (Secondary burn) and over the glass to help keep it clean and clear (Airwash system). The secondary burn feature is a real advantage as this re-burns the initial gasses and smoke produced from the fire. This means you are getting every drop of heat from your fuel and in turn will save you filling the stove up as often, saving you money and time on fuel.

5 Year GuaranteeWoodburning Stove Guarantee

This covers the stove's body and not the internal perishable parts like grates and fire bricks. Guarantee is activated when the stove is invoiced. 6 digit number on the top of each invoice is the warranty number.For stove to be covered it must be installed by a HETAS engineer or signed off by building control.

DEFRA ApprovedCheap Woodburning Stoves

This version of the 5kw Panoramic has been rigorously tested and approved to burn wood in a smoke controlled zones. Defra approved stoves with 5" flue outlets, like this one, can also be installed with a 5" liner. The Defra approval has been achieved by factory fitting a mechanical stop to prevent secondary air closure beyond the 31mm open position. When ordering over the phone please specify that you require the DEFRA version. If not you may be sent the non DEFRA unit.

Stove ConstructionWoodburning Stove Construction

The Panoramic is a "hybrid" stove and its body is constructed from quality Q235B carbon steel, that has been chosen for its plasticity, toughness and weldability. The door is made from very thick mineral cast iron that helps retain the heat and slowly release it into the room. Having a cast iron door also enables us to add features like the shallow curves on the top and bottom. The internal lining is vermiculite. - The stove weighs over 90kg

Stove FeaturesWoodburning Stove Features

  • Eco Design Ready - Approved by HETAS
  • HETAS (Cleaner Choice) approved, with a 66% improvement on the clean air act limit.
  • View on HETAS website.
  • DEFRA APPROVED.
  • Over 80% efficient.
  • Typical log length - 390mm to 400mm long.
  • Woodburning only with flat fire brick base.
  • Reduced distance to combustibles materials (350mm side - 500mm rear)
  • Slimline - 560mm wide but only 5kw.
  • KW Range - 3.6kw to 6.9kw (5kw nominal and shown on data plate.)
  • Suitable for 12mm hearth.
  • Top and rear flue outlet.
  • FREE Ecosy+ printed over glove.
  • Well engineered chrome handle comes with stove as standard. Other handles are available to suit all styles and interiors.
  • Full vermiculite brick lining and base. (No grate or ash pan required for woodburning only stoves.)
  • Finished in heat resistant matt black paint.
  • Flue diameter 125mm (5'') with choice of top or rear flue outlet.
  • Gross weight - 85kg.
  • 10mm thick steel top, 5mm thick body.
  • Pre-heated air wash system to help keep the glass clean.
  • Tertiary air system that re-burns the smoke for a clean and efficient burn.
  • Air Brick/Vent Required? No (Some exceptions apply)
  • Height : 551mm, 21.69 inches.
  • Width: 560mm, 22.04 inches.
  • Depth : 314mm 12.36 inches.
  • Distance from the back of stove to centre of top flue 130mm 5.1 inches.
  • Distance from floor to centre of rear flue outlet 450mm - 17.71 inches.
  • 125mm 5" top and rear flue collar included.
  • Glass Size - 430mm x 375mm
  • Internal stove dimensions - H: 300mm W: 410mm D: 180mm
  • Option: 1000mm length of matching flue.
  • Option: Ceramic glass is not covered under the guarantee for any stove on the market. Ceramic glass is fully heat resistant but will break if struck with a log, or similarly hard object. This glass is expensive, but for a small fee we are offering to guarantee it for a full year. This covers any accidental chips or cracks and photographic evidence will be required. This covers one claim only, not multiple breakages.
  • Option: "Classic Range " Brass or Brushed Chrome Handles.
  • Option: Extra tall log guard Is offered on checkout - Standard Height Is 60mm at the highest point. The additional bar adds 50mm to the overall height.
  • Option: Spare rope kit, glue and glass clips for servicing.
  • Option: Custom Rear Flue Box - Easier to fit and clean. Also reduces the distance that the stove is pushed away from the wall. View full listing here.
  • Option: Stainless Steel Cook Plate And Pan Rain - Great for cooking on - Full listing here.

Why Are We So Cheap?Cheap Woodburning Stoves

This is a common question we get asked and understand why people will sometimes wonder how it can be done so cheap. Through our brands we design a large amount of our products and they come direct from our factory to us. This completely cuts out any middle men. We can stock over 3000 stoves at any one time and ship direct to the end user with no showrooms. We always suggest prospective buyers take a look at our glowing feedback that currently has over 7000 positive comments on our stoves and stove products.

Low Emissions

A clearSkies 4 rating means your stove exceeds Defra and EcoDesign carbon monoxide emissions standards A clearSkies 4 rating means your stove exceeds Defra and EcoDesign nitrogen oxide emissions standards A clearSkies 4 rating means your stove exceeds Defra and EcoDesign particulate matter emissions standards A clearSkies 4 rating means your stove exceeds Defra and EcoDesign organic gaseous compounds emissions standards
The Panoramic stove has been awarded the clearSkies 4 rating

ClearSkies Rating 4

The clearSkies 4 mark tells you that your stove is kinder to the environment. It is an independently assessed endorsement that your stove exceeds all of the latest UK regulations. You've probably heard of the government's EcoDesign directive that ensures all stoves manufactured from 2022 onwards comply with strict environmental measures.

Laboratory Tested

Any stove that has a clearSkies accreditation has been demonstrated to meet scrupulous safety standards for carbon monoxide (CO) and nitrogen oxide (NOx) emissions as well as environmental pollution rules that limit the emission of particulate matter (PM) and organic gaseous compounds (OGC). And that's just the lowest of the clearSkies ratings!

Exceeds All Standards

All stoves with the clearSkies 4 rating, such as the Panoramic Slimline, are approved by Defra, the goverment's Department for Environment, Food & Rural Affairs. Furthermore, they have been tested under laboratory conditions to be even more environmentally friendly than EcoDesign stoves, emitting 15% lower CO, PM, OGC and NOx. So you can feel confident that your new stove has been designed and built for a sustainable, greener future.

Ecosy+ Panoramic Wood Burning Stoves

The Panoramic Range

Panoramic stoves are Ecodesign ready and come in a range of styles and sizes, so there’s a design to fit every home.

Slimline

The original Panoramic is a large wood-only stove that has been made with a smaller internal shell to maintain a 5kw output. This means you can fill a larger fireplace and still have a spectacular view of the fire, but don’t have to worry about installing an air vent (some exceptions apply).

Traditional

The Panoramic Traditional features the same iconic glass front, but the door has been reimagined in a classical style with square details, sitting flatter against the stove than the original and designed to feel at home in a rustic fireplace.

Cast Base

If you have a larger fireplace and are looking for something that will fill it out nicely, the Panoramic with Cast Base or the Panoramic Traditional with Cast Base adds extra height and width and will fit in modern and traditional fireplaces.

Log Store

The Panoramic stove can also be purchased with a fitted log store to really make it a centrepiece. The sturdy log store adds 283mm of height to the stove, and provides a great place to keep plenty of logs warm, dry, and ready to light.

Twin Door

If you are looking for a stove that will really make a statement, the Twin Door Panoramic or the Twin Door Panoramic with Stand are the perfect option. Both make for a stunning centrepiece in a traditional fireplace or freestanding.

Multi-fuel

If you would like to burn smokeless coal as well as wood, we stock a multi-fuel Panoramic and a multi-fuel Panoramic Traditional.

Stove Fittings
Fittings Chrome fittings and long handle for easy use and leverage
Baffle Plate Steel baffle plate
Stove Accessories
Accessories Ash pan/oven glove/tool/manual
Stove Features
Legs Fixed
Grate No Grate - Woodburning only
Efficiency Very efficient "Huge saving on bills" Slow Burn (Efficient)
Cleaning Pre heated airwash system
Seals Heat resistant fire rope seals
Stove Dimensions
Height 551mm
Width 560mm
Depth 314mm
Distance from back of stove to centre of top flue outlet 130mm
Distance from floor to centre of rear flue outlet 450mm
Outlets 125mm 5" top and rear flue collar included
Power 5kw
